Roof Cover Installation
1. Lay the Roof Cover (15) on the ground, next to
the frame, so that the three inside pockets for the
opposite side are facing up as shown in Figure R.
2. Slide two Bottom Rails (5) into the
middle openings of the pocket.
3. Tie a rope(sold separately) to each Bottom Rail.
Roof
Cover
(15)
Bottom
Rails
(5)
Pocket
Rope
Rope
Figure R: Align Roof Cover with Frame
4. Throw the ropes over the top of
the frame to the other side.
5. From the other side, pull the ropes to properly
position the Roof Cover as shown in Figure S.
6. Remove the ropes and Bottom Rails.
Figure S: Position Top Cover
Page 12 For technical questions, please call 1-888-866-5797. 62860
