TROUBLESHOOTING / SPECIFICATION
Others
SPECIFICATION
Product Water Filtration Device
Model CHP-260L CHP-260N
Power Supply Refer to the rating plate.
Water
tank
capacity
Room water 2.5 L
Cold water 2.3 L
Hot water 1.0 L
Total 5.8 L
Dimension 260 mm (W) x 483 mm (D) x 500 mm (H)
Working Temperature 5
º
C - 35
º
C
Production Rate
76 L/d (25
º
C, 0.14 Mpa) 720 L/d (0.10 Mpa)
Working Pressure
137 kPa – 827 kPa 69 kPa – 827 kPa
Net Weight 18 Kg
• The water amount can be dierentiated according to the water pressure and the water
temperature.
• The water tank capacity is the amount by the size and can be dierent from the extraction
capacity.
• Without any prior notice, all or parts of the product are subject to change for the purpose of
improving the performance of the product.
• Refer to Performance data sheet for individual contaminants, reduction performance and general
operating information.
