TROUBLESHOOTING / SPECIFICATION
Others
SPECIFICATION
Product Water Filtration Device
Model CHP-671R CHP-671L
Filtration Method RO(Reverse Osmosis)
Power Supply Refer to the rating plate.
Tank Capacity
Room Water 11.5 L
Cold Water 6 L
Hot Water 3.6 L
Total 21.1 L
Dimension 370 mm(W) × 490 mm(D) × 1 257 mm(H)
Working Temperature 5 °C - 35 °C (41 °F - 95 °F)
Production Rate 282 L/d (25 °C, 0.41 Mpa) 189 L/d (25 °C, 0.14 Mpa)
Working Pressure 69 kPa – 827 kPa 137 kPa – 827 kPa
Net Weight 34.8 kg 32.8 kg
• The water amount can be dierentiated according to the water pressure and the water
temperature.
• The water tank capacity is the amount by the size and can be dierent from the extraction
capacity.
• Without any prior notice, all or parts of the product are subject to change for the purpose of
improving the performance of the product.
• Refer to Performance data sheet for individual contaminants, reduction performance and general
operating information.
