3. INSTALLATION POSITIONS WITHIN THE VEHICLE
Facing the direcon of travel (group 1)
Facing away from the direcon of travel (group 0+)
With the 2-point belt (car seatbelt)
With the front airbag
On seats with:
Group 1:
(1) ISOFIX anchorage points (between the seat and
the seat back) and top tether anchorage points (such as on the rear
shelf, on the ground or behind the seat)
(2) 3-point seatbelts Group 0+: 3-point seatbelts
Group 0+
Group 0+/1
8
4. SETUP WITHIN THE VEHICLE
fig.1
fig.2
Place the child seat in the rear of the vehicle, facing away from the
direcon of travel(group 0) or facing forward(group1).
The child seat must be as closely ached to the vehicle's seat as
possible.
For vehicles with adjustable headrests, a beer installaon can be
achieved by adjusng the height or removing the
headrest(fig.1)(Group1).
It is important to replace the headrest in its posion when an adult
is travelling.
The child seat must not be transported in the vehicle without being
buckled in, even when the child is not travelling in the child seat. It
is very important to keep this in mind, in order to avoid any damage
that the child seat could cause in the event of an accident. The child
seat must therefore remain installed at all mes while driving.
Ensure that the distance between the child seat, installed in the rear
of the vehicle, and the front seats is the maximum possoble.(fig.2).
