15
6. INSTALLATION IN THE VEHICLE / GROUP 1
6.2 CHILD SEAT INSTALLATION (USE 3-POINT SEATBELT)
Only group 1 from approx. 9 months to 4 years of age (9-18kg)
1. Place the child seat in the vehicle, facing from the direcon of
travel. Turn unlock the sha and pull it out.(fig.1)
2. Pull away the seat shell away from theseat base, insert 3-point
seatbelt through seat shell and seat base.(fig.2)
3. Belly part of the 3-poit seatbelt gothrough two below belt
guiders, lock 3-point seatbelt unl you hear a “click”. Then
shoulder part of 3-point seatbelt go through the lock-off
device. Turn the lock-off device and locked. (fig.3)
4. Pulling the 3-point seatbelt to remove any slack, and make
sure there is no twist. Push together the seat shell and seat
base, insert back and turn locked the sha. (fig.4)
1
2
3
4
16
6. INSTALLATION IN THE VEHICLE / GROUP 1
6.3 FASTENING THE CHILD INTO THE CHILD SEAT
1. The correct adjustment of the headrest ensures that the child
is properly fastened into the car seat. The headrest must be
adjusted so that the harness(which moves with the headrest)
is at shoulder height on the child or slightly above, but never
behind the back or at the ear level (fig1)
2. Pull the headrest height adjuster and move headrest to shoulder
height in accordance with the size of the child (fig2)
3. Loosen the harness strap by stretching the chest secon while
holding down the center adjuster(fig3).
4. Open the buckle so that the child can be placed into the seat.
The harness straps can be placed on the armrest(fig4).
5. Place the child into the seat, then fit the safety harness around
the child, using the buckle to fasten the two parts together unl
you hear a “click” (fig5)
6. Stretch the harness adjustment belt in order to give the harness
1
2 3
