CPE 46599 - Parts List

REV 46599-20120703 20
46599 ENGLISH
Parts List
# Part Number Description Qty
1
168FD-2-GC Engine 1
2
504.191100.04 Rotor Assembly 1
3
ST02FD-02100005-2.5 Flange Bolt M8×233
1
4
GB96 8 Washerφ8
1
5
GB7244 8 Lock Washer φ8
1
6
504.191200.04 Stator Assembly
1
7
ST02FD-02100002 Stator Cover
1
8
ST02FD-02100003 End Housing
1
9
ST02FD-02100001-2.5 Flange Bolt M6×158
4
10
GB97.1 6 Washerφ6
6
11
GB93 6 Lock Washer φ6
10
12
ST02FD-02100009 Carbon Bursh
1
13
ST02FD-02100008 Pinch
1
14
GB93 5 Lock Washer φ5
5
15
GB5783 M5 ×16 Bolt M5×16
1
16
GB97.1 5 Washer φ5
2
17
GB5783 M5 ×16 Bolt M5×16
2
18
ST02FD-02100007-CPE AVR
1
19
GB16674 M5X16 Flange Bolt M5×16
2
20
ST02FD-02100004( R) Generator End Cover
1
21
GB16674 M5X12 Flange Bolt M5×12
2
22
ST02FD- 02100010 Terminal Block
1
23
GB818 M5X15 Screw M5×15
2
24
ST188FD -1100010-88 Plate,Spark Arrester
1
25
ST188FD-1180121 Spark Arrester
1
26
468.101000.05 Muffler
1
27
GB5789 M6X12 Flange Bolt M6×12
2
28
ST168FD-1100300-
CARB
Secondary Air Intake Valve
1
29
ST168FD-1100003-
CARB
Gasket,Air Supply Valve
1
30
GB16674 M6X16 Flange Bolt M6×16
2
31
GB6175 M8 Nut M8
2
32
GB93 8 Lock Washer φ8
2
33
GB848 8 Washer φ8
2
34
ST168F-1100200-G Muffler Gasket
1
35
GB5789 M6x8 Flange Bolt M6×8
1
36
ST168FD-1090006-A Holder,Air Cleaner
1
37
ST168FD-1160002-B Pipe,Fuel
1
38
ST188FD-1070006A Clip
2
39
ST02FD-04160000 Fuel Cock
1
40
504.071000.35( R) Fuel Tank
1
41
ST02FD- 04100010 Mount Vibration, Fuel Tank
4
42
ST02FD-04100014 Washer φ6
4
43
GB93 6 Lock Washer φ6
4
44
GB5789 M6×20 Flange Bolt M6×20
4
45
ST168F-1070006A Fuel Tank Filter
1
# Part Number Description Qty
46
168.070100.01 Fuel Tank Cap
1
47
168.070014.01 Pipe,Reversal Valve
1
48
ST160F-1070007 Clamp
1
49
ST168FD-1070400-
CARB
Reversal Valve
1
50
GB819 M5×10 Screw M5×10
2
51
ST02FD-04120000-
CARB
Fuel Meter Assembly
1
52
ST18 8FD -1741002- C Cover,Handle
1
53
ST182FD -1151110- B Handle
1
54
GB6177 M8 Nut M8
14
55
GB5789 M8×45 Flange Bolt M8×45
2
56
ST168FD -1070408-
CARB
Clamp
2
57
ST02FD-0228 Frame
1
58
GB5782 M10 ×105 Bolt M10 ×105
2
59
GB96 10 Flat Washer φ10
2
60
ST02FD-03621001 Bush φ10.5×58.5
2
61
ST177FD-1152300(B) 8in Wheel
2
62
GB6182 M10 Nut M10
2
63
504.201200.00 Motor Mount I
2
64
504.201200.01 Motor Mount II
2
65
GB6177 M6 Nut M6
1
66
ST02FD-02100013-2.5 Grounding Line
1
67
GB5789 M8 ×16 Flange Bolt M8×16
2
68
ST05FD-03020301-60 Support Legφ2.36φ
1
69
ST18 8FD -17430 02- C Vibration Mount
2
70
GB5789 M8×25 Flange Bolt M8×25
2
71
ST02FD-05010703 Flange Bolt M5×13
4
72
2A105 Control Panel
1
73
ST02FD-05702004 Ignition Switch
1
74
ST02FD-05502023 Receptacle 5-20R
2
75
GB823 M4×14 Screw M4×14
4
76
GB848 4 Flat Washer φ4
4
77
GB859 4 Lock Washer φ4
4
78
GB6177 M4 Nut M4
4
79
ST02FD-05302001-L20 Circuit Breaker
2
80
ST02FD-05802001 pilot lamp
1
81
GB5783 M6×22 Bolt M6×22
1
82
GB6175 M6 Nut M6
2
83
ST02FD-05212002 Plug
1
84
ST02FD-05202003 Sheath,Wire
1
85
ST02FD-05212001 Plug
1
86
GB823 M5 ×14 Screw M5x14
1
87
OV01-00000000 Over Voltage Protector
1
88
GB6177 M5 Nut M5
1
89
ST02FD-05202014 Control box
1
