CPE 46599 - Engine Parts List

REV 46599-20120703 22
46599 ENGLISH
# Part Number Description Qty
1
GB5789-FB6-8 Flange Bolt 6 x 8 5
2
ST160F-1061200 Recoil Starter Knob 1
3
160.061100.32 Recoil Starter Assembly
1
4
ST160F-1061005 Recoil Starter Spring
1
5
ST160F-1061009 Recoil Starter Rope
1
6
ST160F-1061001-A Recoil Starter Reel
1
7
ST188F-1060006 Spring, Ratchet
2
8
ST188F-1060005 Starter RatchetφMetalφ
2
9
GB5789-FB6 -12 Flange Bolt M6 x 12
9
10
ST188F-1060003 Ratchet Guide
1
11
ST188F-1060004 Ratchet Guide Spring
1
12
ST188F-1060002 Screw, Ratchet guide
1
13
ST168F-1080100 -G Fan Cover Assembly
1
14
ST160F-1050010 Nut M14
1
15
ST160F-1060001-A Start Hub
1
16
ST168F-1080001 Cooling Fan
1
17
ST168F-112010 0 Flywheel
1
18
ST168F-1080200 Air Guideφφφ
1
19
ST168F-1030100 Oil Seal
2
20
GB5789-FB6 -15 Flange Bolt M6x15
4
21
ST160F-1030003 Drain Bolt
2
22
ST160F-1030004 Washer, Drain Bolt
2
23
ST168F-2-1030012-G Crankcase
1
24
GB276-BB-6205-UU Radial ball bearing 6205
2
25
ST160F-1127000-A Oil Level Sensor
1
26
ST160F-1110108 Washer, Governor φφφ
1
27
ST160F-1110101 Governor Gear
1
28
ST160F-1110102 Pin, Weight
2
29
ST160F-1110104 Shaft, Governor Gear
1
30
ST160F-1110103 Circlip, Governor Gear
1
31
ST160F-1110107 Governor Weight
2
32
ST02FD -1151201A Choke Lever
1
33
ST160F-1110105 -A Bushing, Governor
1
34
ST168FD-2-1050001-A Crankshaft Assembly
1
35
ST168F-1030008-G Gasket, Crankcase
1
36
ST160F-1030001-B Oil Dipstick
1
37
ST160F-1030002 Gasket, Oil Dipstick
2
38
GB5789-FB8-32 Flange Bolt 8 x 32
6
39
ST168F-1110005 Spring, Throttle Return
1
40
ST168F-1110007 Spring, Governor
1
41
ST160F-1110003 Arm, Governor
1
42
GB41-N- 6 Nut M6
3
43
ST160F-111000 8 Pin, Shaft
1
44
ST160F-1110001 Shaft, Governor Arm
1
45
ST168F-1110006 Rod, Governor
1
46
ST160F-111000 4 Bolt, Governor Arm
1
47
GB5789-FB6-25 Flange Bolt 6 x 25
2
48
ST160F-1123000-G Ignition Coil
1
49
152FMD-1001007 Dowel Pin 10 x 16
2
50
GB5789-FB8-55 Flange Bolt 8 x 55
4
51
ST168FD-1090005-G Cover, Air Cleaner
1
52
ST168FD-1090004 Element
1
# Part Number Description Qty
53
ST168FD-1090003 Separator
1
54
ST168FD-1090002 Air Cleaner Seal
1
55
ST168FD-1091000 -
CARB
Base, Air Cleaner
1
56
ST160F-1130003-CPE Gasket, Carburetor
1
57
ST168F-1130001 Insulator, Carburetor
1
58
ST168F-1130002-CPE Gasket, Insulator
1
59
ST160F-1010001 Stud Bolt 6 x 110
2
60
ST168F-2-1010100-G Cylinder Head
1
61
ST168F-2-1030009-G Gasket, Cylinder Head
1
62
ST168F-1040002 Valve, Intake
1
63
ST168F-1040006 Valve, Exhaust
1
64
ST168F-2-10 40013 Lifter,Valve
2
65
ST168F-2-1041000 Camshaft Assembly
1
66
ST168FD-1030007-G Dowel Pin 9 x 14
2
67
ST168FD-1080200-
CARB
Air Shroud, Cylinder
1
68
GB1099-79 Key
1
69
ST168FD-1030007-G Crankcase Cover
1
70
ST168F-1050100 Connecting Rod Assembly
1
71
ST168F-1050003 Wrist Pin
1
72
ST168F-1050004 Circlip, Wrist Pin
2
73
ST168F-2-1050005 Piston
1
74
ST168F-1050007 Ring, First
1
ST168F-1050006 Ring, Second
1
ST168F-105020 0 Ring, Oil
1
75
ST168F-1080002-GC Shroud, Cylinder Head
1
76
GB900-SB8-35 Stud Bolt 8 x 35
2
77
ST168F-1040005 Push Rod
2
78
ST168F-1040014-A Oil Seal, Valve
2
79
ST168F-1040027 Stud Bolt, Rocker Arm
2
80
168.040201.34 Retainer, Rocker Arm
1
81
GB41-N- 6 Nut M6
2
82
168.040004.34 Guide, Push Rod
1
83
ST168FD-1020011-A Breather Tube
1
84
ST168F-1020100 -C Cylinder Cover Assembly
1
85
ST160F-1020002-A Gasket, Cylinder Cover
1
86
ST160F-1040 024 Screw, Valve Adjustment
2
87
ST160F-1040 025 Locknut
2
88
ST160F-1040 022 Rocker Arm
2
89
168.040202.34 Shaft, Rocker Arm
1
90
ST160F-1040008 Rotator, Exhaust Valve
1
91
ST160F-1040001 Retainer, Intake Valve
1
92
ST160F-1040007 Retainer, Exhaust Valve
1
93
ST160F-1040003 Spring, Valve
2
94
F6RTC Spark Plug
1
95
ST168FD-2-1131000-
CPE
Carburetor
1
96
ST168FD-1130005-CPE Gasket, Carburetor
1
97
GB90-W-6 Washer φ6
2
98
ST168FD -2-1131000 -17 Standard Main Jet
1
ST168F-2-1131000 -17 Altitude Main Jet
/
