Operator's Manual
I:RRFTSMRN°
675 Series
LOG SPLITTER
Model No. 247.77614
CAUTION: Before using
this product, read this
manual and follow all
safety rules and operating
instructions.
• SAFETY
ASSEMBLY
OPERATION
MAINTENANCE
PARTS LIST
Spanish
Sears, Roebuck and Co., Hoffman Estates, IL 60179, U.S.A.
Visit our web site: www, sears,corn/craftsrnan FORMNO.769-03352
06/21/2007
