Craftsman 82024 - Page 7

7
Function Range Resolution Accuracy
200  0.1  (0.8% reading + 5 digits)
2 k 0.001 k
20 k 0.01 k
200 k 0.1 k
(0.8% reading + 2 digits)
2 M 0.001 M
Resistance
20 M 0.01 M
(2.5% reading + 8 digits)
0 to 30F / -17 to -1C  15F / 8.3C
31 to 150°F / -0.5 to 65C 6F / 3.3C
Temperature IR
151 to 400°F / 66 to 204C
0.1C/F
4.0% of reading
Enclosure Double molded
Diode Test Test current of 0.9mA maximum, open circuit voltage 2.8V DC typical
Continuity Threshold 20 to 50, test current <1.5mA
Input Impedance 10MΩ VDC/VAC
AC Response True RMS
ACV Bandwidth 40Hz to 1000Hz
IR Spectral response 6 to 16µm
IR Emissivity 0.95 fixed
IR distance ratio 4:1
Laser pointer Class 2 laser < 1mW power; Wavelength is 630 to 670nm
Display 2,000 count backlit liquid crystal display
Overrange indication “OL” is displayed
Auto Power Off 15 minutes (approximately)
Polarity Automatic (no indication for positive); Minus (-) sign for negative
Measurement Rate 2 times per second, nominal
Battery One 9 volt (NEDA 1604) battery
Fuses mA, µA ranges; 200mA 250V ceramic fast blow
A range; 10A 600V ceramic fast blow
Operating Temperature -10ºC to 40ºC (14ºF to 122ºF)
Storage Temperature -10
o
C to 60
o
C (14
o
F to 140
o
F)
Operating Humidity Max 80% up to 31ºC (87ºF) decreasing linearly to 50% at 40ºC (104ºF)
Storage Humidity <80%
Operating Altitude 2000 meters (7000 ft) maximum
Weight 260 g (9.17oz)
Size 147x76x42 mm (5.8x2.9x1.6”)
Safety This meter is intended for origin of installation use and protected, against
the users, by double insulation per IEC/EN 61010-1:2001 and IEC/EN
61010-031:2002 to Category III 600V; Pollution Degree 2.
Approvals CE
