7 - ENG D23377
ASSEMBLY
Tools Required for Assembly
1 - 9/16” socket or open end wrench
1 - 3/8” socket or open end wrench
GLOSSARY
Become familiar with these terms before operating the
unit.
CFM: Cubic feet per minute.
SCFM: Standard cubic feet per minute; a unit of
measure of air delivery.
PSIG: Pounds per square inch gauge; a unit of meas-
ure of pressure.
ASME: American Society of Mechanical Engineers;
made, tested, inspected and registered to meet the
standards of the ASME.
Code Certification: Products that bear one or more
of the following marks: UL, CUL, ETL, CETL, have
been evaluated by OSHA certified independent safety
laboratories and meet the applicable Underwriters
Laboratories Standards for Safety.
Cut-In Pressure: While the motor is off, air tank
pressure drops as you continue to use your accesso-
ry. When the tank pressure drops to the factory set
low pressure the motor will restart automatically. The
low pressure at which the motor automatically restarts
is called “cut-in” pressure.
Cut-Out Pressure: When an air compressor is
turned on and begins to run, air pressure in the air
tank begins to build. It builds to a factory set high
pressure before the motor automatically shuts off -
protecting your air tank from pressure higher than its
capacity. The high pressure at which the motor shuts
off is called “cut-out” pressure.
Branch Circuit: Circuit carrying electricity from elec-
trical panel to outlet.
ACCESSORIES
This unit is capable of powering the following Accessories. The accessories are available through the current
Power and Hand Tool Catalog or full-line Sears stores.
Accessories
• In Line Filter
• Tire Air Chuck
• Quick Connector Sets
(various sizes)
• Air Pressure Regulators
• Oil Fog Lubricators
• Air Hose:
1/4", 3/8" or 1/2" I.D.
in various lengths
Specialty Tools
• Inflating/Blow Gun
• Grease Gun
• Caulk Gun
• Engine Cleaner
• Sand Blaster
Carpentry Tools
• Finishing Nailer / Stapler
• Construction Nailer /
Stapler
Socket Driving
• 1" Impact Wrench
• 3/4" Impact Wrench
• 1/2" Impact Wrench
• 3/8" Impact/Butterfly
Wrench
• 1/2" Ratchet
• 3/8" Ratchet
• 1/4" Ratchet
Material Shaping
• 2.625" Hammer
• 1.625" Hammer
• 1/2" Drill
• 3/8" Drill
• High Speed Rotary
• Mini High Speed Rotary
• Cut-Off Tool
• Shear
• 4" Angle Grinder
• Reciprocating Saw
• Nibbler
Spray Painting
• Multi-Purpose Spray
Gun
• Automotive Spray Gun
• HVLP Spray Gun
Finishing/Sanding
• High Speed Sander
• Random Orbit Sander
• 6" DA Sander
• Jitterbug Sander
• Straight Line Sander
Contents of Carton
1 - Air Compressor
1 - Handle
4 - Self Tapping Screws
2 - Wheels
2 - Shoulder Bolts, 3/8-16
2 - Hex Nuts, 3/8-16
1 - Rubber Strip
