Craftsman 921.166360 - Parts List

1 1 E101207 Intake, Filter Housing,1/2 NPT (Kunsan) 1
2 1 E100435 Filter Element (Kunsan) 1
3 Head Bolt M6 x 1.0 x 30 4
4 Lock Washer 6 mm 8
5 E100227 Cylinder Head 1
6 2 Gasket Head 1
7 E100228 Valve Plate 2
8 E100229 Valve Reed 2
9 2 Gasket Valve Plate 1
10 Gasket Cylinder Upper 1
11 Cylinder, ID42 mm x H65 mm 1
12
Screw, Socket Head, M6 x 1.0 x 20 mm 5
13 2 Gasket, Cylinder Lower 1
14 3
Ring, Compression 2
15 3 Ring, Scraper 1
16 3
Piston 1
17 3 Piston Pin 1
18 3 Snap Ring, 12 mm 2
19 3 Rod, Connecting 1
20 3 Nut, M6 x 1.0 1
21 3
Eccentric 1
22 4 Oil fill cap 1
23 4 O ring, OD17 mm x 2 mm 1
24 E101000 Screw, Hex Flange Head, 4
M5 x 0.8 x 15 mm
25 5 Seal, Oil Sight Gauge 1
26 5 Gauge, Oil Sight 1
27 Cover, Crankcase 1
28 2 Baffle, Rubber 1
29 6 Nut, M8 x 1.25 10
30 Washer, Tooth Lock, 5/16” 2
31 Screw M3 x 0.5 x 6 mm 4
32 Washer, Lock, 3 mm 4
33 E100248 Capacitor, Starting (200uF) 1
34 E100247 Capacitor, Running (40uF) 1
35 Motor 1
36 E100955 Shroud 1
37 Bolt M5 x 5.8 x 10 6
38 Motor Braket 1
39 Flatwasher 8 mm 6
40 Lock Washer 8 mm 6
41 Bolt, M8 x 1.25 x 16 mm 4
42 E100101 Power Cord 1
43 E100957
Pressure Switch 1
44 E100094 Safety Valve 1
45 E100309 Nipple 1/4” NPT x 32 mm 1
46 E102370 Pressure Gauge 1.5” 200 PSI 1
47 E100594 Strain Relief 2
48 E101968 Manifold Tube Male/ Male 1
49 E102125 Pressure Tube Assy 1
50 E100898 Check Valve 1
Reference Kit Part Description Quantity
Number Number Number
Reference Kit Part Description Quantity
Number Number Number
10
Air Compressor Model 166360
Parts List
