Craftsman CM2.12 - Technical Specifications

15 Technical data
Craftsman Marine engine model
Type of engine
CM2.12 CM2.16 CM3.27
General specications
• Basic engine:
Mitsubishi Mitsubishi Mitsubishi
• Bore x stroke: 76 x 70 mm 76 x 70 mm 76 x 70 mm
• Capacity: 635 cm³ 635 cm³ 952 cm³
• Number of cylinders: 2 in line 2 in line 3 in line
• Compression ratio: 23 : 1 23 : 1 22 : 1
• Order of fuel injection: IDI (indirect) IDI (indirect) IDI (indirect)
• Maximum number of revolutions: 2500 rpm 3600 rpm 3600 rpm
• Maximum torque: 25 Nm at 2500 rpm 29,3 Nm at 3600 rpm 53,1 Nmat 3600 rpm
• Maximum output at flywheel: 8,8 kW/12 pk
(ISO 8665/3046)
11,8 kW/16 pk
(ISO 8665/3046)
20 kW/27.2 pk
(ISO 8665/3046)
• Fuel consumption at 1800 rpm: 268 g/kW.h (196 g/pk.h) 268 g/kW.h (196 g/pk.h) 270 g/kW.h (199 g/pk.h)
• Exhaust diameter: Ø 30 Ø 40 Ø 40
• Weight: 90 kg 90 kg 113 kg
40 craftsman marine diesel engines CM2.12 , cm2.16 / cm3.27
