Technical Data
PROPERTY VALUE
VALUE
Model
82TB10 82TB16
No load speed
4500-5500-6000-
6500 rpm ±10%
4500-5000-5500-
6300 rpm ±10%
Cutting head Bump feed Bump feed
Cutting Line Diameter 2 mm
2 mm
Cutting Path Diameter 40 cm 46 cm
Battery pack
82V220G/82V430G/
82V220/82V430
82V220G/82V430G
82V220/82V430
Charger 82C1G/82C2/82C6 82C1G/82C2/82C6
Weight (without battery pack) 5.5 kg 5.83 kg
Lawn
Trimmer
Measured sound
pressure level
L
PA
=74.52dB(A),
K
PA
=3 dB(A)
L
PA
=72.18 dB(A),
K
PA
=3 dB(A)
Measured sound
power level
L
WA
=94.52dB(A) L
WA
=92.18 dB(A)
Guaranteed sound
power level
95 dB(A) 96 dB(A)
Vibration
< 2.5 m/s
2
,
k=1.5m/s
2
< 2.5 m/s
2
,
k=1.5m/s
2
Troubleshooting
PROBLEM
POSSIBLE
CAUSE
SOLUTION
String will not
advance when using
the bump-feed head.
String is weld-
ed to itself.
Replace string.
Not enough
string on spool.
Install more string. Refer to string
replacement earlier in this manual.
String is worn
too short.
Pull string while pressing line release
button.
String is tan-
gled on spool.
Remove string from spool and
rewind. Refer to string replacement
earlier in this manual.
Grass wraps around
shaft housing and
string head.
Cutting tall
grass at ground
level
Cut tall grass from the top down to
prevent wrapping.
Motor fails to start
when switch trigger
is depressed.
Battery is not
secure.
To secure the battery pack, make
sure the latch on bottom of the bat-
tery pack snaps into place.
Battery is not
charged.
Charge the battery pack according
to the instructions included with your
model.
* If the fault is not solved, you must go to your distributor and/or nearest Authorized
Technical Service.
