Cramer TOURNO de Luxe 95

Questions and Answers

M
Michael FriedmanJul 31, 2025
How to fix Cramer Lawn Mower when motor will not start?
- J
  Jennifer TuckerJul 31, 2025
  If your Cramer Lawn Mower's motor won't start, there are several things you can check: * Verify the tank filling level and refill if needed. * If the green indicator lamp isn't lit, examine the basic starting conditions. * Check and adjust the choke setting. * If there's an ignition plug failure, clean the ignition plug contacts or replace the plug. * For a clogged fuel pump, inspect the pump and clean the fuel filter.
M
Mrs. Patricia LoganAug 4, 2025
Why Cramer TOURNO de Luxe 95 Lawn Mower battery cannot be loaded sufficiently?
- C
  carolyn60Aug 4, 2025
  If the battery of your Cramer Lawn Mower isn't loading sufficiently, it could be due to a few reasons: * Damaged battery cells: In this case, you should replace the battery. * Low battery acid level: Refill with distilled water. * Contact problems: Clean and grease the poles.
R
Rebekah FisherAug 9, 2025
What to do if Cramer TOURNO de Luxe 95 Lawn Mower starter does not move?
- D
  davidholtAug 9, 2025
  If the starter on your Cramer Lawn Mower isn't moving, consider these possible solutions: * Check the battery and charge or refill as necessary. * If there's insufficient contact to the battery poles, clean and grease them. * If the green indicator lamp isn't lighting up, verify the prerequisites for starting the machine.
V
Veronica OsborneAug 12, 2025
Why is my Cramer TOURNO de Luxe 95 Lawn Mower motor running rough?
- P
  penacharlesAug 13, 2025
  If your Cramer Lawn Mower motor is running rough, consider the following: * If there's an ignition plug failure, clean the ignition plug contacts or replace the ignition plug. * Clean the air filter. * Clean the fuel filter.
C
Charles BakerAug 17, 2025
How to fix uneven mowing result with Cramer TOURNO de Luxe 95 Lawn Mower?
- M
  Melissa WareAug 17, 2025
  If you're getting an uneven mowing result with your Cramer Lawn Mower, here are a few things to check: * Replace the blades if they are blunt. * Be aware of excessively high speed at insufficient motor rpm. * Ensure the mowing mechanism is set parallel to the ground using the adjustment screws on the mowing mechanism linkage. * Make sure there aren't different pressure levels in the wheels.
N
nhancockAug 21, 2025
Why my Cramer TOURNO de Luxe 95 Lawn Mower vibrates?
- J
  Jennifer BeckAug 21, 2025
  If your Cramer Lawn Mower is vibrating, here are a couple of things you can do: * Tighten the blade bolts. * If the blades are imbalanced, replace them with new, original blades.
H
hudsonkarenAug 27, 2025
What to do if Cramer Lawn Mower drive performance null or weak?
- T
  Todd BaldwinAug 27, 2025
  If the drive performance of your Cramer Lawn Mower is null or weak, the reason may be air in the gear unit. Set both gear units to manual operation, start the motor, and push the accelerator pedal several times, both forward and backward (bleeding). If this doesn't provide sufficient remedy, please contact your authorized dealer.

Summary

Important Information

General Information

Covers manual usage, traffic, and accident prevention regulations.

Safety Symbols Explained

Explanation of DANGER, WARNING, ATTENTION, and NOTE symbols.

Limitation of Liability

Manufacturer's exclusion of liability for improper use or unauthorized parts.

Copyright Notice

Guidelines on permissible copying of the operation manual.

Warranty Terms

Details on warranty coverage and claim procedures.

Safety

Intended Use and Misuse

Machine approved for mowing/mulching; prohibits leaf mulching and slope misuse.

General Risk Sources

Risks from operation, motor, blades, children, pets, and slopes.

Maintenance Safety

Safety measures for servicing, repair, cleaning, and parts.

Operator Qualification

Requirements for operators regarding age, physical, and mental fitness.

Essential Safety Instructions

Read manual, keep safety distance, use protective gear, and handle fire risks.

Safety Devices

Importance of not removing covers and maintaining safety devices.

Environmental Protection

Proper disposal of oils, fuels, filters, and recycling of materials.

Technical Data

Machine Specifications

Details on motors, fuel, speed, steering, tyres, noise, and ambient conditions.

Mower Model Specifications

Dimensions, cutting width, height, blades, weight for different mower models.

Design and Function

Product Overview

Description of TOURNO model features, drive, steering, and mowing mechanism.

Component Identification

Labeled diagram of main machine components.

Operating Panel and Controls

Details on ignition, throttle, choke, indicator lamps, and height adjustment.

Motor-Gear Connection and Pedal Operation

How to connect motor to gear, manual movement, and accelerator pedal use.

Parking Brake Operation

Instructions for engaging and disengaging the parking brake.

Seat Adjustment and Front Device Control

Adjusting driver's seat and operating the front mowing mechanism lift/lower pedal.

Accessory Mounting Points

Locations for attaching accessory devices on the TOURNO model.

Motor Cover Access

Procedure for lifting and opening the motor cover.

Tilting the Mowing Mechanism

Step-by-step instructions for tilting the mowing mechanism upwards for servicing.

Reattaching Mowing Mechanism

Steps to re-secure the mowing mechanism after tilting.

Mulching vs. Discharge Mode

How to switch the mowing mechanism between mulching and discharge.

Mowing Mechanism Inclination Adjustment

Adjusting the rod for optimal mulching inclination.

V-Belt Tensioning Lever

Instructions for engaging and setting the V-belt tensioning lever.

V-Belt Tensioning Procedure

Readjusting the mowing mechanism by tensioning the V-belt.

Working Position and Risk Areas

Defines operator's position and identifies areas of risk.

Accessories and Spare Parts

Requirement to use only original spare parts and accessories.

Transporting the Machine

Steps for transporting the machine without its original packaging.

Storage Guidelines

Recommendations for short-term and long-term storage.

First Commissioning

Commissioning Safety Precautions

Warning about unauthorized restart and missing protective devices.

Assembly Reference

Reference to installation instructions for assembly before commissioning.

Initial Machine Start-up

Procedure for initial machine start and functional testing.

Operation

Pre-Operation Checks

Activities to perform before starting the machine, like topping up fuel.

Starting and Stopping Procedures

Basic steps for starting and stopping the machine and its mowing mechanism.

Normal Operation Guide

Step-by-step process for normal machine operation and driving.

Post-Operation Procedures

Steps to follow after using the machine, including cleaning.

Slope Mowing Safety

Safety tips and risks associated with mowing on slopes.

Mulching Best Practices

Advice for optimal mulching results and grass cutting.

Maintenance

Maintenance Safety

Safety precautions for maintenance work, avoiding injury.

Regular Maintenance Tasks

Procedures for cleaning and checking safety precautions.

Maintenance Schedule Overview

Table outlining scheduled maintenance tasks and intervals.

Troubleshooting

Failure and Accident Safety

Procedure for failures and accidents, including emergency stops.

Service and Support Contact

Information on contacting the sales consultant for issues and support.

Common Issues and Solutions

Table of common failures, causes, and remedies for troubleshooting.

Assembling the Mowing Mechanism

Component Identification

Labeled diagrams of receiver points and mowing mechanisms for different models.

Assembling the Swivel Frame

Step-by-step instructions for assembling the swivel frame.

Hooking Up the Mowing Mechanism

Steps for attaching the mowing mechanism to the machine.

Setting the Mowing Mechanism

Adjusting V-belt tension and setting the mowing mechanism.

Final Height and Guard Adjustment

Setting mowing mechanism height and re-attaching V-belt guard.

EU Declaration of Conformity

Manufacturer and Product Details

Information about Cramer GmbH and the product declaration.

Regulatory Compliance

Lists applicable EU directives and harmonized standards for the product.

Technical Documentation Authority

Details of the person authorized to compile technical documentation.
