TOURNO 696.01-01 As of 2014
Original Operation Manual English
Operation Manual
Models
TOURNO compact 95 TOURNO de Luxe 95
TOURNO compact 115 TOURNO de Luxe 115
TOURNO compact 95 4
WD
TOURNO de Luxe 95
4
WD
TOURNO compact 115 4
WD
TOURNO de Luxe 115
4
WD
Machine no.

Questions and Answers

  • L
    Laura BakerAug 4, 2025
    How to fix Cramer Lawn Mower when motor will not start?
    • H
      Heather WardAug 4, 2025
      If your Cramer Lawn Mower's motor won't start, there are several things you can check: * Verify the tank filling level and refill if needed. * If the green indicator lamp isn't lit, examine the basic starting conditions. * Check and adjust the choke setting. * If there's an ignition plug failure, clean the ignition plug contacts or replace the plug. * For a clogged fuel pump, inspect the pump and clean the fuel filter.
  • C
    Cheryl StoutAug 9, 2025
    Why Cramer TOURNO compact 95 Lawn Mower battery cannot be loaded sufficiently?
    • J
      Jennifer CooperAug 9, 2025
      If the battery of your Cramer Lawn Mower isn't loading sufficiently, it could be due to a few reasons: * Damaged battery cells: In this case, you should replace the battery. * Low battery acid level: Refill with distilled water. * Contact problems: Clean and grease the poles.
  • D
    Debra NicholsonAug 13, 2025
    What to do if Cramer Lawn Mower starter does not move?
    • S
      sandersphillipAug 13, 2025
      If the starter on your Cramer Lawn Mower isn't moving, consider these possible solutions: * Check the battery and charge or refill as necessary. * If there's insufficient contact to the battery poles, clean and grease them. * If the green indicator lamp isn't lighting up, verify the prerequisites for starting the machine.
  • V
    Victoria LyonsAug 17, 2025
    Why is my Cramer TOURNO compact 95 Lawn Mower motor running rough?
    • W
      William HendersonAug 17, 2025
      If your Cramer Lawn Mower motor is running rough, consider the following: * If there's an ignition plug failure, clean the ignition plug contacts or replace the ignition plug. * Clean the air filter. * Clean the fuel filter.
  • K
    Kevin JonesAug 21, 2025
    How to fix uneven mowing result with Cramer Lawn Mower?
    • P
      Peggy SmithAug 22, 2025
      If you're getting an uneven mowing result with your Cramer Lawn Mower, here are a few things to check: * Replace the blades if they are blunt. * Be aware of excessively high speed at insufficient motor rpm. * Ensure the mowing mechanism is set parallel to the ground using the adjustment screws on the mowing mechanism linkage. * Make sure there aren't different pressure levels in the wheels.
  • C
    Caitlyn DickersonAug 27, 2025
    Why my Cramer Lawn Mower vibrates?
    • T
      Thomas GutierrezAug 27, 2025
      If your Cramer Lawn Mower is vibrating, here are a couple of things you can do: * Tighten the blade bolts. * If the blades are imbalanced, replace them with new, original blades.
  • M
    michael46Aug 30, 2025
    What to do if Cramer Lawn Mower drive performance null or weak?
    • L
      Lisa PachecoAug 30, 2025
      If the drive performance of your Cramer Lawn Mower is null or weak, the reason may be air in the gear unit. Set both gear units to manual operation, start the motor, and push the accelerator pedal several times, both forward and backward (bleeding). If this doesn't provide sufficient remedy, please contact your authorized dealer.

Summary

Safety

Operational Risks and Hazards

Covers motor, blade, slope, child, pet risks, and general operational hazards.

Required Protection and Safety Devices

Mandatory personal protective equipment, safety devices, and fire response.

Technical Data

Machine and Motor Specifications

Technical details of motors, fuel, speeds, dimensions, and noise emissions.

Design and Function

Operating Panel and Controls Explained

Detailed guide to the operating panel, indicators, ignition, and throttle controls.

Mowing Mechanism Lift and Lower System

Step-by-step instructions for operating the front mowing mechanism's lift and lower functions.

Tilting the Mowing Mechanism Upwards

Detailed steps for safely tilting the mowing mechanism for maintenance or cleaning.

Returning the Mowing Mechanism to Position

Instructions for swivelling the mowing mechanism back after tilting.

Selecting Mowing Mode: Mulching or Discharge

How to switch between mulching and discharge functions using the adjustment lever.

Adjusting Mowing Mechanism Inclination

Using the adjustment rod to set the mowing mechanism's forward tilt.

Readjusting Mowing Mechanism V-Belt Tension

Procedure for adjusting the V-belt tension of the mowing mechanism.

First Commissioning and Setup

Machine Startup and Functional Test

Steps for filling fuel, starting the machine, and performing a functional test.

Operation

Maintenance

Troubleshooting

Common Issues, Causes, and Solutions

Table of common machine failures, their probable causes, and remedies.

Assembling the Mowing Mechanism

Cramer TOURNO compact 95 Specifications

General IconGeneral
BrandCramer
ModelTOURNO compact 95
CategoryLawn Mower
LanguageEnglish
