Cramer TOURNO compact 95 - Readjusting Mowing Mechanism V-Belt Tension

TOURNO 696.01-01 15 of 26 As of 2014
Original Operation Manual English
V-belt tensioning
Readjusting the mowing mechanism
1. Loosen the lock nut (2).
2. Loosen the nut (1).
3. The belt can be tensioned by adjusting the tensioning
screw (3).
4.
Secure: first tighten the nut (1), then the lock nut (2).
