TOURNO 696.01-01 23 of 26 AS OF 2014
Original Operation Manual English
A2: Hooking up the mowing
mechanism
8. Loosen the two star handle
screws and remove the V-belt
guard from the mowing
mechanism
9. Push the mowing mechanism
under the swivel arm.
10. Raise the mowing mechanism
at the back and push the steel
tongue into the rectangular
opening in the machine.
11. Secure the mowing mechanism
using the screw provided.
