OPERATOR’S MANUAL
5
OVERVIEW - TORQUESTAR OPTA
TorqueStar Opta is the equipment of choice for the measurement and collection of torque data in the manufacturing
environment.
TorqueStar Opta’s range of software features can be individually specified to give a configuration most suited to the
requirement, from a simple no-frills read-out to a comprehensive audit tool with display of torque curves and special-
ist measurement routines.
The basic TorqueStar Opta performs bi-directional measurement of torque, angle and pulse count in track, peak,
click and pulse measurement modes. For additional information, cycle time duration and tool speed can also be
displayed.
Time and date stamped readings can be set to print automatically. The easy to read display gives a simultaneous
view of all relevant information during the measurement process, while the simple alphanumeric keypad enables fast
data entry when required.
Light enough for carrying on a neckstrap, yet robust to withstand the rigours of the factory environment, TorqueStar
Opta also sports integrated rubber bumpers to protect finished product from accidental damage.
The TorqueStar Opta supports the following features:
• Multiple languages
• Track, peak, 1
st
peak (click) and pulse measurement modes
• Torque, angle, pulse count, cycle time and RPM measurement
• Choice of measurement units
• Plug and play with Crane UTA transducers and wrenches
• Compatible with most 3
rd
party transducers and wrenches
• Selectable auto-print of time and date stamped readings
• Optional Storage of time and date stamped readings
• Optional Basic statistics including range, mean, sigma, Cp and CpK
• Optional Storage of Jobs and rounds including readings
• Optional Operator login with Password Protection
• Optional Bar Code Reader Input
• Optional Graphic Display and Printout of Last Rundown Trace
• Optional PC Communications Package
• Force
SECTION 1
