V8 GUITAR AMPLIFIER
V8 TECHNICAL SPECIFICATIONS:
OUTPUT POWER RATING 5 Watts RMS @ 10 % THD, 4 ohm load, 120VAC
INPUT IMPEDANCE 1M ohm
MAX. SIGNAL ACCEPTED 2.5V peak-to-peak
SIGNAL TO NOISE RATIO 66dB
GAIN 58dB
TONE CONTROL +/-16dB @ 1kHz
LINE OUT LEVEL 80mV RMS
INTERNAL SPEAKER 10”, 4 ohm, 15W Celestion
POWER REQUIREMENTS 120VAC, 60 Hz, 40VA
100/115 VAC, 50/60Hz, 40VA
230 VAC, 50/60Hz, 40VA
SIZE AND WEIGHT 12” H x 13” W x 7.5” D, 18 lbs.
The V8 is covered with a durable Tolex material: wipe it clean with a lint-free cloth.
Never spray cleaning agents onto the cabinet. Avoid abrasive cleansers which would damage the finish.
Specifications and information in this manual are subject to change without notice.
www.crateamps.com
@2005 SLM Electronics, a division of St. Louis Music, Inc • 1400 Ferguson Avenue • St. Louis, MO 63133
47-609-03 • 020405
