Crate Pro Audio CSM12 - Gain Level Diagram

CSM8/12/16/24 Console Mixer
Gain Level Diagram:
+30
+10
+20
-10
0
-20
-40
-30
-60
-50
-70
-120 NOISE FLOOR -120dB
dB
MAX MIC +13dB
MAX LINE +26dB
+21dB+21dB
MAIN OUT
+4dB
+15dB
+3dB
-17dB
-23dB
-13dB
-7dB
MAX. INPUT - SET GAIN AS NECESSARY
ALL LEVELS @NOMINAL,
GAINS @"10"
FULL GAIN
MIC -49dB
MIC -72dB
LINE -35dB
LINE -55dB
MIC
LINE
FADER
PAN
INSERT
GAIN
MASTER
FADER
EQ
15
