PX700DLX/PX900DLX Powered Mixer
Technical Specifications
Due to ongoing product development and improvement, the specifications contained herein are subject to change without notice.
MAXIMUM VOLTAGE GAIN 86dB Ch In (Lo-Z) to Power Amp Out (Ch 1-4)
(PAD OFF) 66dB Ch In (Lo-Z) to Main Out, Monitor Out (Ch 1-4)
72dB Ch In (Lo-Z) to Effect Out (Ch 1-4)
50dB Ch In (Lo-Z) to Rec Out (Ch 1-4)
54dB Ch In (Hi-Z) to Main Out, Monitor Out (Ch 1-4)
25dB Aux In to Main Out
73dB Mic In to Main Out, Monitor Out (Ch 5-7/5-9)
28dB Line In to Main Out, Monitor Out (Ch 5-7/5-9)
INPUT CHANNEL EQUALIZATION ±15dB Maximum
High: 12kHz (shelving); Mid: 2.5kHz (peaking); Low: 80Hz (shelving)
FREQUENCY RESPONSE +1/-3dB, 20Hz-20kHz @ 1W output into 8Ω (Power Amp Out)
+1/-3dB, 20Hz-20kHz @ +4dB output into 10kΩ (Main Out, Monitor Out, Effects Send)
MAXIMUM OUTPUT POWER 200W/4Ω @ 0.5% THD @ 1kHz
TOTAL HARMONIC DISTORTION <0.3% @ 20Hz-20kHz, 100W output into 4Ω (Power Amp Out)
<0.3% @ 20Hz-20kHz, +14dB output into 10kΩ (Main Out, Monitor Out, Effects Send)
HUM AND NOISE -122dB equivalent input noise, -63dB residual output noise
(Average, Rs=150Ω) (Power Amp Out)
(with 20Hz-20kHz BPF) -78dB residual output noise (Main Out, Monitor Out, Effects Send)
-73dB (77dB S/N) (Main Out, Monitor Out) All channel level controls at minimum
-40dB (44dB S/N) (Main Out, Monitor Out) One channel level controls at maximum
-74dB (78dB S/N) Effects Send All channel level controls at minimum
-34dB (38dB S/N) Effects Send One channel level controls at maximum
CROSSTALK @ 1kHz 63dB adjacent input, 63dB input to output
GRAPHIC EQUALIZER 7 bands (125Hz, 250Hz, 500Hz, 1kHz, 2kHz, 4kHz, 8kHz) ±12dB Maximum
INTERNAL DIGITAL EFFECT 4 types (Digital Delay, Vocal, Large Hall, Small Hall)
PHANTOM POWER +48V is supplied to electrically balanced inputs for powering condenser microphones via 6.8kΩ current
limiting/isolating resistors
LIMITER LED ON Output Level: 36dB
FOOT SWITCH DSP Mute: on/off
POWER CONSUMPTION 200W
SIZE AND WEIGHT PX700DLX: 18.9” (480mm) W x 10.8” (275mm) H x 10.8” (275mm) D; 37.5 lbs (17kg)
PX900DLX: 21.6” (546mm) W x 10.8” (275mm) H x 10.8” (275mm) D; 39 lbs (17.7kg)
