Functions - LEVELLER menu SW1 Save?
L07
Set limit for service interval in operating time (in 24h days)
(default 365 days). Service interval disabled when set to 0.
+1 Yes
L08
Address of the control unit on CMS-network (1-255) (default 255). +1 Yes
L09
CMS-Network baudrate (U00=38400bps (default) or
U01=187500 bps).
+1 Yes
L10
Auto return with one or two press on AUTO button.
U00=Leveller, door and shelter returns. (default)
U01=Leveller return on first press, door and shelter on next press.
+1 Yes
L11
External interlock of leveller (S9).
U00= door photocell to detect open door.
U01= door limit switch to detect open door. (default)
U02= CDM9 to detect open door (from a pre-selected door pos.).
Run the door to the wanted position go in and set L11 to UO2.
+1 Yes
L12
Hydraulic motor current adjustment.
2.6A
3.2A
3.8A
4.4A (default SwingDock).
5.0A
5.6A (default TeleDock).
6.2A
6.8A
7.4A
8.0A
8.6A
9.2A
+1 Yes
L13
Cross-traffic switch (S6) exist or not.
U00= Cross-traffic switch installed.
U01= No switch installed (door located behind leveller). (default).
+1 Yes
L14
Lift/swing lip extend timer T2 1 – 19sec. (default 5sec.). +1 Yes
L15
Swing lip fold in timer T3 5 – 20sec. (default 11sec.). +1 Yes
L16
Return leveller timer T4 3 – 30sec. (default swingdock 5sec.
teledock 9sec.).
+1 Yes
L17
RZ-Automatic timer T5 0 – 2.0sec. (default 0sec.). +0,1 Yes
L18
Start shelter - open door timer T6 0 – 30sec. (default 10sec.). +1 Yes
L19
Close door – stop shelter timer T7 0 – 30sec. (default 30sec.). +1 Yes
L20
Service reset (total)
Change to U01 and save.
(Resets all error lists and counters for leveller and door).
+1
Yes
L21
Lock/unlock Control unit (default U00).
U00 = Unlock control unit.
U01 = Lock control unit (a key is shown in the display).
+1 Yes
L22
Numbers of valves for Swingdock. (default U00).
U00 = Default by variant detection in button panel on the lid.
U01 = Swingdock one valve function (overrides variant detection).
U02 = Swingdock two valves function (overrides variant detection).
+1 Yes
