Crawford ECS 950 - Page 14

- Page 14 -
Functions - LEVELLER menu SW1 Save?
L23
The input functionality for X18:2 (default U00).
U00 = Start shelter – open door (default).
U01 = Close door – stop shelter.
U02 = Start shelter and open door outside.
U03 = Autoclose of door on/off.
U04 = Doors extra safety.
U05 = Close door. (Overrides any U01 on L23-L25).
U06 = Open door, open in the lid disconnected.
+1 Yes
L24
The input functionality for X18:3 (default U01).
U00 = Start shelter – open door.
U01 = Close door – stop shelter (default).
U02 = Start shelter and open door outside.
U03 = Autoclose of door on/off.
U04 = doors extra safety.
U05 = Close door.
U06 = Open door, open in the lid disconnected.
+1 Yes
L25
The input functionality for X18:4 (default U04).
U00 = Start shelter – open door.
U01 = Close door – stop shelter.
U02 = Open door outside.
U03 = Autoclose of door on/off.
U04 = doors extra safety (default).
U05 = Close door.
U06 = Open door, open in the lid disconnected.
+1 Yes
L26
The output functionality for K12, X25:1 – 2 (default U05).
U00 = Indication Open door.
U01 = Indication Closed door.
U02 = Electrical door lock output.
U03 = Flashing light.
U04 = Leveller in resting position S6.
U05 = Truck in position S15 (default).
U06 = French light.
U07 = Error indication. (except E08).
U08 = Steady light.
U09 = Not open door.
U10 = Not closed door.
+1 Yes
L27
The output functionality for K13, X25:3 – 4 (default U04).
U00 = Indication Open door.
U01 = Indication Closed door.
U02 = Electrical door lock output.
U03 = Flashing light.
U04 = Leveller in resting position S6 (default).
U05 = Truck in position S15.
U06 = French light.
U07 = Error indication (except E08).
U08 = Steady light.
U09 = Not open door.
U10 = Not closed door.
+1 Yes
