10 Rows of Holes
13 Rows of Holes
Top
Pocket Shelf
2
Attach LB Swing Lid to LB Swing Side 1.
Insert Phillips head screwdriver at a
slight angle into installed Locking Cams.
Turn clockwise until tight.
Slide Pocket Shelf over
Connecting Bolts in LS1.
Make sure the open side is facing
the lid and unfinished edge is facing
the groove for the back panel.
Tighten two Locking Cams.
3
diL
LS
LS1
Screw in at a 45
degree angle.
Screw in at a 45
degree angle.
