3
7
Proprietary, patented product and assembly instructions. Do not copy or distribute.
Proprietary, patented product and assembly instructions. Do not copy or distribute.
CB Shelf 1
5
CB Base
4
Stand CB 1 on its edge, finished edge up. Be sure
posts, dowels & pins are aligned. Push CB 1
carefully into CB Base.
Use a shelf from your shelf bundle to support
attached side pieces.
Center Box
CB Base
CB 1
CB 1
F20
Lock cams in place by turning
220 degrees.
7
Proprietary, patented product and assembly instructions. Do not copy or distribute.
