Create Room Sew Station - Page 35

32
26
LH
If attaching to DreamBox 1, install sash lock corresponding with your configuration choice.
Use the sticker to help guide the location of your screws. You will need to self tap.
Use the provided screws to attach
(1) Sash Lock Catch (per side)
with the hook near the edge of the
table using the sticker as a guide.
side edge of the DreamBox table
(near the outer end)
Final Step: Press bumper in between Sewstation
and DreamBox 1 table to prevent damage.
