Create Room Sew Station - Connect to DreamBox 2

33
LHLH
LHLH
Install Locking Posts and Cams. Attach to DreamBox 2
by sliding Locking Posts into the grooves of the
DreamBox 2 table until it clicks in place. Add Hole Plugs.
RIGHT SIDE DREAMBOX ATTACHMENT:
LEFT SIDE DREAMBOX ATTACHMENT:
CONNECTING TO DREAMBOX 2
HARDWARE NEEDED FOR
CONNECTING TO DREAMBOX 2:
x2
8mm Hole Plugs
x2
Cams
x2
Locking Posts
x2
8mm Hole Plugs
x2
Locking Cams
x2
Locking Posts
x2
8mm Hole Plugs
x2
Cams
x2
Locking Posts
26
27
Install Cams with
arrow facing OUT
Install Cams with
arrow facing OUT
