ENGLISH
REMOTE CONTROL CONNECTION
Green/yellow stripe
Grey DC motor L
Pink DC motor L
Red DC motor L
Input L
Input N
Ground
wire
L
N
Receiver place: Hook the motor on the left hook, and then conduct wiring
1 2 3
Time Saver: Washers for blade screws can be set on each blade screw prior to installing-
blades.
Align blade holes with motor screw holes, then securely tighten all the screws once all the
blades are attached. Before securing screws permanently, repeat with remaining blade
arms.
Note: Tighten blade screws twice.
BLADE ASSEMBLY
WIND CALM
WITHOUT LED LIGHT
To Next Page
