ENGLISH
12
LIST OF PARTS
Carefully open the packaging. Remove items from Styrofoam inserts. Remove motor housing
and place on carpet or Styrofoam to avoid damage to nish. Check against parts inventory
that all parts have been included.
Hanger bracket Blades X3
Motor Remote control
Spiral package
The outlet box and joist must be securely mounted and capable of reliably supporting at
least the weight of the fan.
INSTALLATION INSTRUCTIONS
FIXING THE MOUNTING BRACKET
Wooden ceiling
Securely attach the mounting bracket with
wood screws and washers to the ceiling
joints.
Concrete ceiling
Bore holes with an 8mm drill, according to
the length of the expansion screws. After
that, x the mounting bracket to the ceiling
with the expansion screws.
Don’t x the mounting bracket directly on ceilings thinner than 10mm to avoid the risk of the
screw coming loose.
WIND CALM WITHOUT LED LIGHT
