ENGLISH
8
INSTALLATION INSTRUCTIONS
• Mark the correct position of the holes and x the mounting bracket using the screws with
metal plugs or screws and washers suitable for the type of ceiling chosen.
• Check the correct installation of the bracket before hanging the fan. This plate must
support the full weight of the fan.
• To avoid personal injury and damage,
make sure the place to hang the blades
leaves a clearance of 2.3 m from the
ground and 76 cm from any walls or
obstacles.
• Make sure the mounting bracket is
securely attached to the building
structure and can support the full weight
of the fan.
INSTALLATION PREPARATION
76 cm of
separation
between
the wall or
obstacle.
2.3 m from
the blades
to the
ground
ELECTRIC CONNECTION
• Make the connection between the cables of the electrical installation of your home and the
cables of the fan motor following the instructions below.
Take
ground
Take
ground
L
N
Light L
Neutral N
Motor L
