Creda Heating Solution - TSR Supaslim Combi: Storage Fan Heaters; TSR Supaslim Combi Technical Specification

23
+44 (0) 1733 456789 www.creda-heating.co.uk
Model Reference Rating Direct Charge Net Storage Weight Number Number of
Storage Acting Acceptance (7hrs) of Elements Core Bricks
TSR12CW 79348 1.7kW 1/0.5kW 11.8kWh 12.6kWh 78kg 2 8
TSR18CW 79358 2.5kW 1.5/0.75kW 17.6kWh 18.5kWh 114kg 3 12
TSR24CW 79368 3.4kW 2/1kW 23.5kWh 25.0kWh 149kg 4 16
TSR12ACW 75 772001 1.7kW 1/0.5kW 11.8kWh 12.6kWh 78kg 2 8
TSR18ACW 75 772002 2.5kW 1.5/0.75kW 17.6kWh 18.5kWh 114kg 3 12
TSR24ACW 75 772003 3.4kW 2/1kW 23.5kWh 25.0kWh 149kg 4 16
TSR Supaslim Combi
Storage fan heaters
Effectively two heaters in one, the built-in
fan can provide heat on its own or in
combination with the storage heater for a
rapid boost to room temperature.
Key features
• Combines economic tariff rate storage heater
with a fast and responsive Warmflow fan heater
for instant room heating
• The slimmest storage combination heater available
• Sensamatic fully automatic storage heater output
ensures room comfort levels are maintained
throughout the day without user intervention
• The Warmflow fan heater has manually
adjustable room temperature sensing thermostatic
control accurate to within 0.5°C
• Warmflow gives better heat distribution, helping
to avoid heat stratification
• Quiet, low velocity Warmflow fan
• All controls are concealed behind a lockable flap
• CW range manually adjustable hydraulic
charge control thermostat
• ACW range has hydraulic input charge
control thermostat providing auto-set
input charge control
• Fan heater ratings can be set on full or
half load (installation option)
• Automatic fan heater switch-off during off-peak
tariff periods (installation override option)
• Elements (storage) - mineral insulated stainless
steel sheathed
• Insulation - opacified silicaceous aerogel and
mineral fibre mat
• Storage Core - high density iron oxide compound
• Fan Unit - crossflow
• Controls - hydraulic head temperature
compensated, room and storage core temperature
sensitive, auto-set charge control
• Protection - two level thermal safety overheat
• Supply - 230/240V AC single phase
Technical Specification
Dimensions
Product Selector
Model Height A Width B Depth C
TSR12CW/ACW 760mm 560mm 170mm
TSR18CW/ACW 760mm 788mm 170mm
TSR24CW/ACW 760mm 1016mm 170mm
“
The Creda Supaslim
Combi heater is designed
to combine economic and
has efficient storage
heating using low-cost
tariff electricity with an
independently thermostat-
controlled fan heater.
”
Electric storage
heating
