Creda Heating Solution - TSR Sensor Plus & Slimline: Electric Storage Heaters; TSR Sensor Plus & Slimline Technical Specification

Working on any low-cost tariff, these
heaters monitor the room temperature and
energy stored within the heater core to
avoid overcharging. This can save up to
15% of the energy used by ordinary
storage heaters.
Key features
• Multi-sense two thermostatic sensor control
system for heat storage and room
temperature control
• The only storage heater available that
automatically monitors and controls heat output
through a thermostatic sensor
• Controls couldn’t be simpler - one for input
and one for output
• Multi-sense system enables energy savings
of up to 15%
• Multi-sense operates exclusively at maximum
efficiency on all economy tariff periods
• Automatic control means little if any control
adjustment - just set and forget
• All Multi-sense sensors are mounted within
the heater
• Lockable controls cover
TSR Slimline (MW) models offer the same
range of sizes and outputs but with simple
manual input and output controls.
* TSR6AW/MW have no user controls and
are IPX2 rated (drip-proof)
• Elements (storage) - mineral insulated stainless
steel sheathed
• Insulation - opacified silicaceous aerogel and
mineral fibre mat
• Storage Core - high density iron oxide compound
• Controls* (Output) - manually adjustable
thermostat controlling output damper.
• Controls (Input) - hydraulic charge control
thermostat, manually adjustable
• Protection - two level thermal safety overheat
• Supply - 230/240V AC single phase
Model Reference Rating Charge Charge Weight Number Number of
Storage Acceptance (7 hrs) Acceptance (8 hrs) of Elements Core Bricks
TSR6AW 79331 0.9kW 6.3kWh 7.2kWh 41kg 1 4
TSR12AW 79341 1.68kW 11.8kWh 12.6kWh 77kg 2 8
TSR18AW 79351 2.5kW 17.6kWh 18.5kWh 110kg 3 12
TSR24AW 79361 3.4kW 23.5kWh 25kWh 145kg 4 16
TSR6MW 79334 0.9kW 6.3kWh 7.2kWh 41kg 1 4
TSR12MW 79344 1.68kW 11.8kWh 12.6kWh 77kg 2 8
TSR18MW 79354 2.5kW 17.6kWh 18.5kWh 110kg 3 12
TSR24MW 79364 3.4kW 23.5kWh 25kWh 145kg 4 16
Model Height A Width B Depth C
TSR6A/MW 705mm 335mm 170mm
TSR12A/MW 705mm 560mm 170mm
TSR18A/MW 705mm 788mm 170mm
TSR24A/MW 705mm 1016mm 170mm
TSR Sensor Plus & Slimline
Electric storage heaters
24
+44 (0) 1733 456789 www.creda-heating.co.uk
Product Selector
Technical Specification
Dimensions
“
The Multi-sense system in
the TSR Sensor Plus
(AW models) automatically
controls heat storage to
maintain the desired room
temperature.
”
Electric storage
heating
