2V (40Hz-400Hz)
0.001V
±(0.9% rdg + 3dgt)
20V (40Hz-400Hz)
0.01V
200V (40Hz-400Hz)
0.1V
600V (40Hz-200Hz)
1V
±(1.2% )rdg + 3dgt
* Over load protection: Maximum 600V DC or AC RMS
4.2.3 Resistance
Resolution
Accuracy
0.1Ω
±(0.8% rdg + 2dgt)
0.001kΩ
0.01kΩ
0.1kΩ
0.001MΩ
±(1.0% rdg + 2dgt)
0.01MΩ
4.2.4 Diode check
Resolution
Function
0.001V
Will display the forward drop voltage.
* Operating current:about 1mA
* Open circuit voltage:about 1.48V
4.2.5 Continuity
Range
Function
If measured resistance less than 100Ω, will buzzer is sounded.
* Open voltage: about 0.5V
4.2.6 DC Current
