Crenova MS8233D - Page 8

Range
Resolution
Accuracy
200µA
0.1μA
±（1.5% rdg + 3dgt）
2000µA
1µA
20mA
0.01mA
200mA
0.1mA
10A
0.01A
* Over Load protection：use the fuse(F250mA/250V) at µA /mA range,
and use the fuse(F10A/250V) at 10A range.
* Max input current: ： 250mA at ‘mA’ input terminal and 10A at ‘10A’ input
terminal.
4.2.7 AC Current [40Hz-400Hz]
Range
Resolution
Accuracy
200µA
0.1µA
（1.5% rdg + 4dgt）
2000µA
1µA
20mA
0.01mA
200mA
0.1mA
10A
0.01A
* Over Load protection：Use the fuse (F250mA/250V) at µA /mA range, and use
the fuse(F10A/250V) at 10A range.
* Max input current: ： 250mA at ‘mA’ input terminal and 10A at ‘10A’ input
terminal...
* Frequency response：40 ～ 400Hz
4.2.8 Frequency
Range
Resolution
Accuracy
20kHz
10 KHz
±（1.5%rdg+5dgt）
* Sensitivity： 0.8V
7
