DISPLAY WINDOW MESSAGES Some of the readouts look odd at first since the control is unable to produce certain
letters or capital letters. You will soon get used to the meaning. The following are the display messages and their meanings:
DISPLAY DESCRIPTION
CHG° Displays after pressing °F or °C SELECT key.
ConE The control is waiting for you to input a cone number between 022 and 10.
CPLt The control is waiting for you to turn the power switch off after completing a firing
profile. The control displays the current internal temperature.
Err See table on errors, a software error has occured.
FAIL The thermocouple is not properly connected to the control or the thermocouple needs to
be replaced. Replace the thermocouple if the connections are OK.
FA5T Fast firing profile
HLd (1 -6) The control is waiting for the user to enter a hold time in hours and minutes.
IdLE Control is awake but awaiting instructions.
nn-5 Medium slow speed firing profile (nn equals m, 5 equals S)
nnEd Medium speed firing profile
nn-F Medium fast firing profile
PF The control is saying there was a power failure for more than 2 minutes or that the kiln
was turned off for more than two minutes.
rA (1-6) For each segment, the control is waiting for the user to enter a temperature rate of rise in
°F per hour or °C per hour.
SEGS (IT’S NOT SE65) The control is waiting for the user to enter the number of segments in
the profile being programmed.
SlO Slow speed firing profile
Spd The control is waiting for the user to enter the speed for this firing - SLOW, MED-SLOW,
MED, MED-FAST, or FAST.
°F (1-6) The control is waiting for the user to enter an end temperature in °F for a segment of the
firing profile in RAMP HOLD mode.
°C (1-6) The control is waiting for the user to enter an end temperature in °C for a segment of
the firing profile in RAMP HOLD mode.
Flashing Temp The element power is off and the kiln is cooling. The display shows the current temperature .
Flashing Time Indicates the kiln is in the hold stage during a RAMP HOLD firing profile. The time
remaining in the hold segment is displayed alternately with the temperature.
Temperature (not flashing) Current kiln temperature during a firing.
12.34 (or other) Shows hours and minutes. In this example 12 hours and 34 minutes.
(Note: period separates hours and minutes in the display.)
