Cressi AC2 - Page 16

65
ENGLISH
1.5 - Performance
Working pressure (INT connection)
Working pressure (DIN connection)
Calibration pressure (200 bar feeding)
Air supply
High pressure (HP) ports
Low pressure (LP) ports
0÷230 bar - (0÷3365 psi)
0÷300 bar - (0÷4350 psi)
10 bar - (145 psi)
2100 l/min (*)
1
4
AC2 in-line piston 1st stage
(*) Values measured at LP port with second stage connected and tank pressure at 200 ➡150 bar (2900 ➡2175 psi)
