matrix sends
The X-VCA includes four MATRIX
outputs. Each of these outputs can be made up
of signals from the eight
GROUPS; the left, right and mono buses; and an external
source. See Master section for more information. For expanded Matrixing capabil-
ities, a 37 pin d-sub connector is included on the rare panel which contains all or
the primary outputs. See Group module rear panel description for more informa-
tion.
matrix 1–4 levels—M1,M2,M3,M4
These level controls are used to mix the group's signal into the correspond-
ing matrix.
post-group
The
GROUP
fader setting has no effect on the group-to-matrix level controls
1–4.
The
GROUP
fader is introduced into the signal path and will control the signal
level.When the group is muted, the group's signals to matrix 1-4 are muted as
well.
p. 45
group module
3
