Entertainment System Crestron Adagio™ AES
Configure Preset Groups
Preset groups can be created to group speakers in adjacent rooms with a specified
source, or switch into a whole-house “party” mode, by letting the user link a source
with any number of rooms. Changing the source in any one room changes the source
in all of the rooms in the preset group.
Edit a Preset Group
To edit a preset group:
• Press and hold a preset group button for approximately five seconds to view
the Edit Group controls shown below. The selected preset group button will
flash.
Edit Group Controls
Edit Group 1
Source: No Source Sele
Name: Group 1
SOURCE
ROOM
HOUSE
MENU
BKLT
SCHED
DISPLAY
MORE
DoneNameSourceCancel
• Select the rooms in the preset group by pressing the corresponding room
buttons on the AES or AAE (if connected). Each room button’s LED will
turn on. Press again to remove the room from the preset group. The room
button’s LED will turn off.
• Select a source for the preset group by pressing the soft button labeled
Source. Turn the selection knob clockwise or counterclockwise until the
desired source is displayed on the LCD.
• Press the soft button labeled Name to change the name of the preset group.
The group name controls will be displayed. Select letters (upper and lower-
case) by turning the selection knob until the desired letter is displayed.
Move the cursor to another position by pressing the soft buttons labeled g
and h. To delete a character, press the soft button marked Del.
NOTE: The maximum length for any preset group name is 16 characters.
Edit Group Name Controls
Edit Group 1
Source: No Source Sele
Name: Group 1
SOURCE
ROOM
HOUSE
MENU
BKLT
SCHED
DISPLAY
MORE
Done><Del
• After editing the preset group, press Done to save the changes and return to
the previous operating mode.
36 • Entertainment System: Adagio AES Operations Guide – DOC. 6456B
