Entertainment System Crestron Adagio™ AES
Available models are:
• AES: AES with ATC-AMFM2 Tuner Card
• AES-XM: AES with ATC-AMFMXM Tuner Card
• AES-SR: AES with ATC-AMFMSR Tuner Card (available soon)
• AESI: AES for International (230 VAC) use with ATC-AMFM2 Tuner
Card
Out of the box, the AES can support one AAS (Adagio Audio Server), one AAE
(Adagio Audio Expander) for control of up to 12 zones, one CEN-IDOC (Interface
for Apple iPod
®
), and a combination of up to 12 C2N-DBF12 (12-button keypads) or
APAD controllers for local control of each zone.
With custom programming (via Adagio Composer, Crestron SystemBuilder™ , or
SIMPL™ Windows
®
) and additional AAEs, the AES can control up to 24 zones of
audio. Additional APADS, C2N-DBF12s, CEN-IDOCs and AAS devices can also be
added as well as other Crestron peripherals.
Specifications
Specifications for the AES are listed in the following table.
AES Specifications
SPECIFICATION DETAILS
Processor
CPU
Processing Speed
32-bit Freescale ColdFire
®
Microprocessor
66 MIPS (Dhrystone 2.1 Benchmark)
Memory 8MB Flash, 32MB SDRAM, 256KB NVRAM
Operating System
Real-time, preemptive, multitasking kernel,
multi-threaded, FAT32 file system with long
names; supports SIMPL Windows and
SIMPL+
®
Ethernet
10/100BaseT, static IP or DHCP/DNS, SSL,
autonegotiating, full duplex TCP/IP,
UDP/IP, SMTP, SNMP, built-in Web server
and e-mail client; supports Crestron
e-Control
®
2 XPanel and RoomView
®
applications
Audio Specifications
(Typical of six room outputs)
Controls
Preamplifier Output
Frequency Response
Volume Range
Bass Range (100Hz)
Treble Range (10kHz)
Total Harmonic Distortion
(THD)
Volume, Balance, Bass, Treble, Loudness,
Mute, Mono, Input Compensation
(6) unbalanced line-level audio outputs;
Selectable for variable or fixed level;
20Hz to 20kHz ±0.2dB
-80dB to +20dB, 1dB steps
±12dB @100Hz, 2dB steps
±12dB @10kHz, 2dB steps
< 0.05%
(Continued on following page)
4 • Entertainment System: Adagio AES Operations Guide – DOC. 6456B
