Crestron Adagio™ AES Entertainment System
AES Specifications (Continued)
SPECIFICATION DETAILS
Audio Specifications (Continued)
Signal-to-Noise Ratio
(SNR)
Stereo Separation
Mute
Maximum Output
Output Impedance:
Amplifier Output
Power
Frequency Response
Signal-to-Noise Ratio
(SNR)
Total Harmonic Distortion
(THD)
Stereo Separation
> 100dB
>80dB
-100dB (electronic),
-120dB (relay)
2.5 V
rms
100 Ohms
45 Watts into 8 Ohms
60 Watts into 4 Ohms
20Hz to 20kHz ±0.75dB
100dB
0.05%
> 75dB
Inputs
Audio
Maximum Input
Input Impedance
Input Compensation
Tuner Card Slots
Infrared
Digital
Input Impedance
Logic Threshold
(10) unbalanced stereo line-level audio
inputs with parallel loop-thrus; connect to
outputs of sources, with loop-thru to AAE;
Inputs 1 through 6 reserved for optional
tuner cards (if installed)
3.2 V
rms
(flat)
47k Ohms
±10dB
(3) Reserved for optional:
• ATC-AMFM2 Adagio Dual AM/FM
Tuner Card
• ATC-AMFMXM Adagio AM/FM and
XM Satellite Radio Tuner Card
• ATC-AMFMSR Adagio AM/FM and
SIRIUS Satellite Radio Tuner Card
(1) mini-phone jack; For connection of the
CNXRMIRD IR detector (sold separately);
Allows IR wireless control from third-party
universal remotes using RC-5 IR
commands
(4) digital inputs; Rated for 0-24V DC,
referenced to GND;
2.2k ohms pulled up to 5V DC
2.5V DC nominal
Outputs
Infrared/Serial
IR output
(8) mini-phone jack, IR/Serial port;
Up to 1.2 MHz
(Continued on following page)
Operations Guide – DOC. 6456B Entertainment System: Adagio AES • 5
