Entertainment System Crestron Adagio™ AES
AES Specifications (Continued)
SPECIFICATION DETAILS
Outputs (continued)
Serial output
Relay
Rating
One-way serial TTL/RS-232 (0-5V) up to
9600 baud
(4) Normally open, isolated relays;
1A, 30V AC/DC; MOV arc suppression
across contacts
Communication
Cresnet
®
Serial
Console
Ethernet
(6) Cresnet Master ports, provide data and
power for C2N-DBF12 keypads and APAD
devices
(2) Cresnet Master ports, paralleled with six
Cresnet ports previously described, provide
data to connected Adagio Audio Expanders
(AAE)
(2) DB9, male, bidirectional RS-232 ports;
Up to 115.2k baud, hardware and software
handshaking support for communication
with serial devices
(1) RJ-11 female, bidirectional RS-232
computer console port for connection to PC
(1) USB 1.1 (Type B female) computer
console port for connection to PC
(1) RJ-45 port for Ethernet communications
Power
Internal Power Supply
AES/AES-XM/AES-SR
AESI
Available Cresnet Power
Heat Dissipation*
8-ohm impedance
4-ohm impedance
7 Amps, 120 Volts AC @ 60Hz
3.5 Amps, 230 Volts AC @ 50Hz
20 Watts (0.83 Amps @ 24 Volts DC)
650 BTU/hr
750 BTU/hr
LCD Display
Green LCD dot matrix, 128 x 64 resolution,
adjustable LED backlight
Environmental
Temperature
Humidity
41° to 104°F (5° to 40°C)
10% to 90% RH (non-condensing)
Enclosure
Black metal with molded ABS/PC front
panel
Dimensions
Height
Width
Depth
7.39 in (18.78 cm)
17.16 in (43.58 cm)
18.60 in (47.24 cm)
Weight 43 lb (19.5 kg)
* BTU/hr ratings made while all channels loaded to 1/8 full power with specified impedance.
(Continued on following page)
