Cameo
™
Keypads Crestron C2N/C2NI-CB Series
5. Attach the desired Decora style faceplate (not supplied).
6. Turn the Cresnet system power ON.
UK-Style Mounting Installation
The keypad for UK-style mounting installation is supplied partially
assembled along with several items as listed in the following table.
Supplied Parts/Assemblies – UK-Style Mounting
QTY ITEM DESCRIPTION
1
Rear housing and switch
assembly
Rear housing with switch circuitry attached
1 Bezel Bezel assembly
1 Plastic wall plate Alternate mounting device and bezel support
1
4-pin female mini network
connector
Used to connect Cresnet network cable to the keypad
(Continued on next page)
18 • Cameo™ Keypads: C2N/C2NI-CB Series Operations & Installation Guide - DOC. 6346A
