Bridging/Mono Interface Crestron CNXBRMO
NOTE: When bridging, no more than two CNXBRMO units should be
connected to a single CNAMPX-16X60 (or CNAMPX-12X60). When
implementing a two CNXBRMO bridge, Crestron recommends
connecting one to ROOM INPUTS 1 & 2 and connecting the other to
ROOM INPUTS 7 & 8 on the CNAMPX-16X60 (or ROOM INPUTS 5
& 6 on the CNSMPX-12X60). Failure to make these connections in this
particular application may result in damage to the amplifier.
8 • Bridging/Mono Interface: CNXBRMO Operations Guide – DOC. 8158A
