Bridging/Mono Interface Crestron CNXBRMO
2-Series
Control System
Cresnet Distribution Block
CNX-PAD8A
CNAMPX-16x60
SPEAKER
A
SPEAKER
B
SET TOGGLE
SWITCH TO MONO
NOTE:
IF MORE THAN ONE SPEAKER
IS PLACED IN THE SAME ROOM,
KEEP SPEAKER A WITH D AND
B WITH C, ETC.
SPEAKER
C
SPEAKER
D
CNXBRMO Used to Provide All Summed Mono
