Crestron DM-RMC-SCALER-C Quick Guide

DM-RMC-SCALER-C DigitalMedia 8G+
™
Receiver & Room Controller w/Scaler
crestron.com
|
800.237.2041
1366x768@60Hz
[7]
, 1400x1050@60Hz
[7]
, 1440x900@60Hz
[7]
,
1600x900@60Hz
[8]
, 1600x1200@60Hz, 1680x1050@60Hz
[7]
,
1920x1080@50Hz (1080p50), 1920x1080@60Hz (1080p60),
1920x1200@60Hz
[8]
, 2048x1152@60Hz
[8]
Scaler Output Resolutions, Interlaced: 720x480@30Hz (480i),
720x576@25Hz (576i), 1920x1080@25Hz (1080i25), 1920x1080@30Hz
(1080i30)
Pass-Thru Output Resolutions: Matched to input
Audio
Input Signal Types: DM 8G+, HDBaseT
Output Signal Type: HDMI
Formats: Dolby Digital
®
, Dolby Digital EX, Dolby Digital Plus,
Dolby
®
TrueHD, DTS
®
, DTS-ES, DTS 96/24, DTS-HD High Res,
DTS-HD Master Audio
™
, Up to 8ch PCM
Communications
DigitalMedia: DM 8G+, HDCP management, EDID format management,
CEC, HDBaseT compliant
Ethernet: 10/100 Mbps, auto-switching, auto-negotiating, auto-discovery,
full/half duplex, DHCP
USB: Supports signal extension of USB HID class devices, expandable to
support virtually any USB 1.1 or 2.0 device using Crestron USB-EXT-DM
USB Extenders
[5]
Connectors – Bottom
HDMI OUT: (1) 19-pin Type A HDMI female;
HDMI digital video/audio output;
Also supports DVI
[3]
USB HID: (1) USB Type A female;
USB 2.0 host port for connection of a mouse/keyboard or other USB HID-
compliant device
COM: (1) 5-pin 3.5mm detachable terminal block;
Bidirectional RS-232 port;
Up to 115.2k baud, hardware and software handshaking support
IR 1 – 2: (1) 4-pin 3.5mm detachable terminal block comprising (2) IR/
Serial ports;
IR output up to 1.1 MHz;
1-way serial TTL/RS-232 (0-5 Volts) up to 19200 baud
Connectors – Top
LAN: (1) 8-wire RJ45 female, shielded;
10Base-T/100Base-TX Ethernet port
24VDC 0.75A MAX: (1) 2.1 x 5.5 mm DC power connector;
24 Volt DC power input;
PW-2407WU power pack included
Connectors – Rear
G: (1) 6-32 screw, chassis ground lug
DM IN: (1) 8-pin RJ45 female, shielded;
DM 8G+ input, HDBaseT compliant;
Connects to the DM 8G+ output of a DM switcher, transmitter, or other DM
device, or to a HDBaseT device, via CAT5e or Crestron DM-CBL-8G cable
[1]
Controls & Indicators
PWR: (1) green LED, indicates operating power supplied via local
power pack
DM LINK: (1) green LED, indicates DM link status
VIDEO: (1) green LED, indicates video signal presence and lock status
USB HID: (1) green LED, indicates a valid device connection and activity
on the USB HID port
SETUP: (1) red LED and (1) miniature recessed pushbutton, for
Ethernet setup
RESET: (1) miniature recessed pushbutton, for hardware reset
LAN (Top): (2) LEDs, green LED indicates Ethernet link status, amber LED
indicates Ethernet activity
DM IN (Rear): (2) LEDs, green LED indicates DM link status, amber LED
indicates video and HDCP signal presence
Power Requirements
Power Pack: 0.75 Amps @ 24 Volts DC;
100-240 Volts AC, 50/60 Hz power pack, model PW-2407WU included
Environmental
Temperature: 32° to 104°F (0° to 40°C)
Humidity: 10% to 90% RH (non-condensing)
Heat Dissipation: 41 BTU/Hr
Enclosure
Chassis: Metal, black finish, vented sides and front
Mounting: Mounts to a 2-gang electrical box, 2-gang UK (BS 4662)
electrical box, or 2-gang European (DIN 49073) electrical box
Dimensions
Height: 7.62 in (194 mm)
Width: 7.61 in (194 mm)
Depth: 1.46 in (37 mm)
Weight
1.90 lb (0.87 kg)

Crestron DM-RMC-SCALER-C Specifications

General

Product color	Black
Heat dissipation	41 BTU/h
Housing material	Metal
Scaled resolutions	640 x 480, 800 x 600, 848 x 480, 1024 x 768, 1280 x 1024, 1280 x 720, 1280 x 768, 1280 x 800, 1360 x 768, 1366 x 768, 1400 x 1050, 1440 x 900, 1600 x 1200, 1600 x 900, 1680 x 1050, 1920 x 1080, 1920 x 1200
RJ-45 ports quantity	1
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
AC adapter frequency	50/60 Hz
AC adapter input current	0.75 A
AC adapter input voltage	100-240 V

Weight and Dimensions

Depth	37 mm
Width	194 mm
Weight	870 g
