HD-MD-400-C-E HD Scaling Auto-Switcher & Extender 400
crestron.com
|
800.237.2041
Connectors – Receiver
HDMI, INPUT 1: (1) 19-pin Type A HDMI female;
HDMI digital video/audio input;
(DVI & Dual-Mode DisplayPort compatible
[2]
)
FROM TX, INPUT 2: (1) 8-pin RJ45 female, shielded;
Signal extension link input port;
Connects to the TO RX port of the companion receiver via CAT5e or
Crestron DM-CBL-8G cable
[1]
HDMI OUTPUT: (1) 19-pin Type A HDMI female;
HDMI digital video/audio output (DVI compatible
[5]
)
AUDIO L/R: (1) 5-pin 3.5mm detachable terminal block;
Balanced/unbalanced stereo line-level audio output
[6]
;
Maximum Output Level: 4 Vrms balanced, 2 Vrms unbalanced
Output Impedance: 200 Ohms balanced, 100 Ohms unbalanced
IR: (1) 2-pin 3.5 mm detachable terminal block;
(Reserved for future use)
COM: (1) 5-pin 3.5 mm detachable terminal block;
Bidirectional RS-232 port;
Up to 115.2k baud, hardware and software handshaking support
LAN: (1) 8-pin RJ45 female;
10Base-T/100Base-TX Ethernet port
24VDC 1.25A: (1) 2.1 x 5.5 mm DC power connector;
24 Volt DC power input;
PW-2412WU power pack included
[13]
SERVICE: (1) USB Type A female;
For factory use only
Connectors – Transmitter
HDMI, INPUT 2 – 3: (2) 19-pin Type A HDMI female;
HDMI digital video/audio inputs;
(DVI & Dual-Mode DisplayPort compatible
[2]
)
VGA, INPUT 4: (1) HD15 female;
RGB (VGA) or component video input
[3]
;
Formats: RGBHV, RGBS, RGsB, YPbPr
AUDIO, INPUT: (1) 3.5 mm TRS mini phone jack;
Unbalanced stereo line-level audio input
[4]
;
Maximum Input Level: 2 Vrms;
Input Impedance: 44k Ohms
TO RX: (1) 8-pin RJ45 female, shielded;
Signal extension link output port;
Connects to the FROM TX, INPUT 2 port of the companion receiver via
CAT5e or Crestron DM-CBL-8G cable
[1]
24VDC 1.25A: (1) 2.1 x 5.5 mm DC power connector;
24 Volt DC power input;
PW-2412WU power pack included
[13]
SERVICE: (1) USB Type A female;
For factory use only
Controls & Indicators – Receiver
FROM TX, INPUT 2: (2) LEDs, green LED indicates signal extension link
status, amber LED indicates video and HDCP signal presence
LAN: (2) LEDs, green LED indicates Ethernet link status, amber LED
indicates Ethernet activity
PWR: (1) Bi-color green/amber LED, indicates operating power is supplied
from power pack via 24VDC input or link to companion transmitter, turns
amber while booting and green when operating
AUTO: (1) Pushbutton to enable/disable auto-switching mode, and (1)
green LED to indicate auto-switching mode it enabled
INPUT 1 – 2: (2) Pushbuttons for manual input selection, and (2) bi-color
green/amber LEDs to indicate the current active input and signal presence
at each corresponding input
SETUP: (1) Red LED and (1) recessed pushbutton for Ethernet setup
Controls & Indicators – Transmitter
TO RX: (2) LEDs, green LED indicates signal extension link status, amber
LED indicates video and HDCP signal presence
PWR: (1) Bi-color green/amber LED, indicates operating power is
supplied from power pack via 24VDC input or link to companion receiver,
turns amber while booting and green when operating
AUTO: (1) Pushbutton to enable/disable auto-switching mode, and (1)
green LED to indicate auto-switching mode it enabled
INPUT 2 – 4: (3) Pushbuttons for manual input selection, and (3) bi-color
green/amber LEDs to indicate the current active input and signal presence
at each corresponding input
SETUP: (1) Red LED and (1) recessed pushbutton for Ethernet setup
Power Requirements
Power Pack: 1.25 Amps @ 24 Volts DC;
100-240 Volts AC, 50/60 Hz power pack, model PW-2412WU included;
NOTE: The power pack connects to either the transmitter or receiver,
not both.
Power Consumption: 13 Watts typical
Environmental
Temperature: 32° to 104°F (0° to 40°C)
Humidity: 20% to 90% RH (non-condensing)
Heat Dissipation: 44.3 BTU/hr
Enclosure (x2)
Chassis: Metal, black finish, with (2) integral mounting flanges,
vented sides
Mounting: Freestanding, surface mount, or attach to a single rack rail
Dimensions
Receiver: Height: 4.94 in (126 mm)
Width: 7.70 in (196 mm)
Depth: 1.11 in (28 mm)
To Next Page
