HD-MD-400-C-E HD Scaling Auto-Switcher & Extender 400
crestron.com
|
800.237.2041
Transmitter: Height: 5.12 in (130 mm)
Width: 7.70 in (196 mm)
Depth: 1.11 in (28 mm)
Weight
Receiver: 1.30 lb (590 g)
Transmitter: 1.25 lb (567 g)
MODELS & ACCESSORIES
Available Models
HD-MD-400-C-E: HD Scaling Auto-Switcher & Extender 400
Included Accessories
PW-2412WU: Wall Mount Power Pack, 24VDC, 1.25A, 2.1mm, Universal
(Qty. 1 included)
Available Accessories
CEN-AVF-HUB: .AV Framework
™
Hub
DM-CBL-8G-NP: DigitalMedia 8G
™
Cable, non-plenum
DM-CBL-8G-P: DigitalMedia 8G
™
Cable, plenum
DM-8G-CONN-WG: Connector with Wire Guide for DM-CBL-8G
DM-8G-CRIMP-WG: Crimping Tool for DM-8G-CONN-WG
DM-8G-CONN: Connector for DM-CBL-8G
DM-8G-CRIMP: Crimping Tool for DM-8G-CONN
CBL Series: Crestron
®
Certified Interface Cables
MP-WP Series: Media Presentation Wall Plates
MPI-WP Series: Media Presentation Wall Plates - International Version
CNSP-XX: Custom Serial Interface Cable
IRP2: IR Emitter Probe w/Terminal Block Connector
AM-100: AirMedia
®
Presentation Gateway
CCS-SPK-SB-100: Sound Bar
MP-AMP30: Media Presentation Audio Amplifier
Notes:
1. The maximum cable length for the signal extension link between the transmitter and receiver is
230 feet (70 meters) using Crestron DM-CBL-8G DigitalMedia 8G cable or third-party CAT5e
(or better). Shielded cable and connectors are recommended to safeguard against
unpredictable environmental electrical noise. All wire and cables are sold separately. The signal
extension link is a proprietary interface and is not compatible with HDBaseT
®
, DigitalMedia
™
(DM
®
), Ethernet, or any other CATx based interface.
2. Each HDMI input requires an appropriate adapter or interface cable to accommodate a DVI or
Dual-Mode DisplayPort signal. CBL-HD-DVI interface cables are available separately.
3. The VGA input can accept RGB and component video signals through an appropriate adapter
(not included).
4. The analog audio input currently works exclusively with the VGA video input. The ability to
pair the analog audio input with an HDMI video input will be enabled through a future
firmware update.
5. The HDMI output requires an appropriate adapter or interface cable to accommodate a DVI
signal. CBL-HD-DVI interface cables are available separately.
6. The analog stereo audio output is only active when the input is receiving a 2-channel stereo
signal via either the analog input or HDMI.
7. EDID (Extended Display Identification Data) is data embedded in an HDMI, DVI, or VGA signal
that enables the display device to tell the scaler what resolutions and formats it can support,
allowing the scaler to configure itself automatically to feed an optimal output signal to
the display.
8. IR control capability will be enabled through a future firmware update.
9. Item(s) sold separately.
10. Supports any input resolution and scan rate that has a pixel clock of 165 MHz or lower.
11. With or without reduced blanking.
12. With reduced blanking only.
13. The transmitter and receiver are powered together by a single wall mount power pack
(included), which may be connected to either the transmitter or receiver, not both.
This product may be purchased from an authorized Crestron dealer. To find a dealer, please
contact the Crestron sales representative for your area. A list of sales representatives is available
online at www.crestron.com/salesreps or by calling 800-237-2041.
The specific patents that cover Crestron products are listed online at: patents.crestron.com.
Certain Crestron products contain open source software. For specific information, please visit
www.crestron.com/opensource.
Crestron, the Crestron logo, .AV Framework, AirMedia, Crestron Fusion, DigitalMedia,
DigitalMedia 8G, DM, and QuickSwitch HD are either trademarks or registered trademarks of
Crestron Electronics, Inc. in the United States and/or other countries. Blu-ray is either a trade-
mark or registered trademark of the Blu-ray Disc Association in the United States and/or other
countries. Dolby Digital is either a trademark or registered trademark of Dolby Laboratories in
the United States and/or other countries. DTS is either a trademark or registered trademark of
DTS, Inc. in the United States and/or other countries. HDBaseT is either a trademark or registered
trademark of the HDBaseT Alliance in the United States and/or other countries. HDMI and the
HDMI Logo are either trademarks or registered trademarks of HDMI Licensing LLC in the United
States and/or other countries. Other trademarks, registered trademarks, and trade names may
be used in this document to refer to either the entities claiming the marks and names or their
products. Crestron disclaims any proprietary interest in the marks and names of others. Crestron
is not responsible for errors in typography or photography. Specifications are subject to change
without notice. ©2016 Crestron Electronics, Inc.
