10
Door Swing Reversal (Optional)
4
Locate the cabinet left corner top
hinge cover in the accessories bag
shipped with the appliance. Detach the
door light switch from the previously
removed right corner top hinge cover
and attach it to the left corner top
hinge cover according to the following
instructions.
To detach switch:
1. Insert flat blade screwdriver tip
into gap between non-plunger side
of switch and hinge cover wall.
Carefully pry back tip against wall to
release that side of switch.
2. Push and hold plunger all the way in
and raise switch out of hinge cover.
To attach switch:
1. Secure tab on non-plunger side of
switch beneath its hinge cover wall
hook.
2. Raise switch slightly and push plunger
down against side of hinge cover wall.
3. Lower switch down to secure tab on
plunger side beneath its hinge cover
wall hook. At same time plunger will
pop through its hole in hinge cover
wall.
To Next Page
