11
5
Remove screws and bushing attaching
door stopper to door bottom left
corner. If necessary use flat blade
screwdriver to pry bushing out.
Remove stopper. Reverse orientation
of stopper and insert bushing and
screws to attach stopper to door
bottom right corner. With aid of
assistant lower the door onto the
bottom hinge so that the bottom hinge
pin inserts into the door stopper
bushing.
Door stopper
Bushing
6
Locate the cabinet left corner top
hinge in the accessories bag shipped
with the appliance. With screws
removed in step 1, use a 10mm box
end or socket wrench to attach the left
corner top hinge to the cabinet left top
corner. Attach wire harness to door
light switch in left top corner hinge
cover. Use screws removed in step 1 to
attach hinge cover to cabinet left top
corner. Use screw removed in step 1 to
attach rectangular cover into position
on cabinet right top corner.
