Cassette Operation
3031
3233
27 28
29
Radio Operation
1 Slide the FUNCTION SWITCH (8) to the Radio
position.
2 Slide the AM/FM SWITCH (17) to the desired
tuning band.
3 Select the desired radio station by rotating
TUNING KNOB (16).
4 Adjust the VOLUME KNOB (9) to the desired
sound level.
Antenna: for FM reception, the unit is provided with
a FM WIRE ANTENNA (33) , move the wire until
the reception is clear and with no interferences. For
AM reception, the unit is provided with a directional
build-in ferrite antenna. Rotate the set to find the
position in which the best reception is obtained. Do
not connect the FM WIRE ANTENNA (33) to any
outside antenna.
1 Slide the FUNCTION SWITCH (8) to the TAPE
position.
2 Insert a prerecorded tape through the CASSETTE
DOOR (25).Tape will slide into the cassette
mechanism and start playing.
3 Adjust the volume level by turning the VOLUME
KNOB (9).
4 For fast forwarding, press the CASSETTE
EJECT/F.F (24) half way in. Pressing again,
will stop the fast forwarding and return the
cassette to the playing mode.
5 To stop and eject the cassette,press the
CASSETTE EJECT/F.F (24) in completely.
6 When one side of the tape finishes playing, the
cassette will automatically stop.
Note:Remove the tape from the unit when it is not
in use or stopped.
Control Locators
Unit Controls
26 Spindle
27 Turntable
28 Adapter For 45 rpm Records
29 Tone Arm
30 Speed Control Switch
31 Tone Arm Rest
32 AC Power Cord
33 FM Wire Antenna
5
Cassette & Radio Operation
8
26
Antenna
To Next Page
